Microwave Noise Absorbing Sheet
1. The microwave noise absorbing sheet can suppress or absorb noise radiation from electronic devices. This sheet has great performance of reflection attenuation and electromagnetic wave suppression.
2. The insulating ink-type absorbing coating features easy printability, strong adhesion, insulation properties, and electromagnetic wave absorption. Different from the conductive ink which will directly reflect electromagnetic waves and even cause the motherboard to short-circuit, this product can improve the problem of noise interference and speed reduction, and is suitable for ultra-high frequency gaming motherboards above 5GHz.
Microwave Noise Absorbing Sheet
Type Products Frequency Area
W*L mm		 Applications Thickness
mm		 TDS
Reflection L,S,C 1~8GHz 205*205 •Satellite navigation communication
•Microwave communication 		1.0/1.5/2.0/2.5/3.0
X 8~12GHz
Ku 12~18GHz 0.2/0.5/1.0/1.5
Ka 18~40GHz
Penetration RF Series 1~18GHz 0.1/0.2/0.5/1.0/2.0
EW100 Series
Insulating inks
Absorbing paints 		AP-40-E Series 10MHz~8GHz Canned Printed on the PCB board on the line or
on the noise source 		1KG/10KG
AP-80-E Series
